Simulation-based Bayesian Optimization

Roi Naveiro

CUNEF University

Cheap yet effective way of doing research

• Take a problem from the Comp. Sci. / ML community

• Bring the statistical perspective / stats. methodology

• Why?

  • Very mathy/formal for Comp. Sci. / ML reviewers ;)
  • Very fancy form Stat. reviewers

The CS problem

Find extreme of objective function

\[\begin{equation*} \arg\max_{x \in \mathcal{S}} f(x) \end{equation*}\]

• Possibly discrete structured domain \(\mathcal{S}\) (e.g. \(\mathcal{S} = [k]^p\))

• No closed form for \(f(x)\)

• \(f(x)\) is expensive to evaluate

• We can query at \(x\) and obtain a (possibly noisy) evaluation of \(f(x)\)

• Many applications e.g., molecular design

Goal

• Get good estimates of global maximum, with few objective function evaluations

• A possible way to go: Bayesian Optimization

Bayesian Optimization (in a nutshell)

Imagine we have access to: \(\mathcal{D}_{1:T} = \lbrace x_t, y_t \rbrace_{t=1}^T\) where

\[y_t \equiv y(x_t) \equiv f(x_t) + \epsilon, ~~~~~ \epsilon \sim \mathcal{N}(0, \sigma^2)\]

Problem: We have budget for \(H\) function evaluations. Using all available info, decide where to evaluate: \(x_{T+1}, \dots, x_{T+H}\)

Solution: Locations maximizing Posterior Predictive Utility¹ …too hard, go greedy: just decide next location!

1. Following Bayesian Decision Theory principles

Bayesian Optimization (in a nutshell)

To do this:

1. Create probabilistic model of response \(y\) given covariates \(x\)

2. Given prior knowledge about \(f(x)\) and evidence coming from \(\mathcal{D}_{1:T}\), summarise our beliefs about result if we query at \(\bf{x_{T+1}}\) through the Posterior Predictive Distribution

\[\begin{equation*} \pi[y_{T+1} | x_{T+1}, \mathcal{D}_{1:T}] \end{equation*}\]

Bayesian Optimization (in a nutshell)

3. Find

\[\begin{eqnarray*} x^*_{T+1} &=& \arg\max_{x_{T+1} \in \mathcal{S}} \mathbb{E}_{y_{T+1} | x_{T+1}, \mathcal{D}_{1:T}} [u(y_{T+1}, x_{T+1} )] \\ &=&\arg\max_{x_{T+1} \in \mathcal{S}} \int u(y_{T+1}, x_{T+1} ) \pi(y_{T+1} | x_{T+1}, \mathcal{D}_{1:T}) d y_{T+1} \end{eqnarray*}\]

Bayesian Optimization - Difficulties

\(\mathcal{S}\) could be a combinatorial search space (or even more complex!). We need:

1. Suitable models of response given covariates

2. Solve a combinatorial optimization in Step 3 (whose objective function might not have a closed-form).

The Stat. Technique - SBBO

We propose Simulation Based Bayesian Optimization (SBBO): an approach to 2 that just requires sampling from posterior predictive distribution

\[\begin{equation*} \pi[y_{T+1} | x_{T+1}, \mathcal{D}_{1:T}] \end{equation*}\]

allowing us to use a wide variaty of models which are suitable for combinatorial spaces

SBBO - Main idea

Convert posterior predictive utility maximization into a simulation problem.

The PPU is:

\[\begin{eqnarray*} \Psi(x) \equiv \int u(y, x ) \cdot \pi(y \vert x, \mathcal{D}_{1:T} ) d y \end{eqnarray*}\]

Given non-negative and bounded utility, recast EU maximization as a simulation from

\[\begin{eqnarray*} g(x, y) \propto u(y, x ) \cdot \pi(y \vert x, \mathcal{D}_{1:T} ) \end{eqnarray*}\]

NOTE: mode of marginal in \(x\) is \(x^*_{T+1}\)!

SBBO - Main idea

• We could simulate from \(x,y \sim g(y, x)\) and find the mode in \(x\)… just limited for low dimensional \(x\)

SBBO - Main idea

• Alternative, Muller et. al. (2004): augmented distribution

\[\begin{eqnarray*} g_H(x, y_1, \dots, y_H) \propto \prod_{h=1}^H u(y^h, x ) \cdot \pi(y^h \vert x, \mathcal{D}_{1:T} ) \end{eqnarray*}\]

Marginal in \(x\)

\[\begin{eqnarray*} g_H(x) \propto \Psi(x)^H \end{eqnarray*}\]

SBBO - Main idea

Inhomogeneus MCMC simulation from \(g_H(y, x)\) with increasing \(H=H_n\) such that stationary distribution for fixed \(H_n\) is \(g_{H_n}\), converges to uniform over set of posterior predictive utility maxmizers

SBBO - Gibbs

Let’s define

\[\begin{eqnarray*} g_H(x, y_1, \dots, y_H) \propto \exp \left \lbrace \sum_{h=1}^H \log[ u(y^h, x ) ] + \log [\pi(y^h \vert x, \mathcal{D}_{1:T}) ] \right \rbrace \end{eqnarray*}\]

SBBO - Gibbs

Recall \(x \in [k]^p\) is a \(p\)-dimensional vector of \(k\)-levels categorical variables. Then:

\[\begin{eqnarray*} g_H(x_q \vert \cdot) \propto \exp \left \lbrace \sum_{h=1}^H \log[ u(y^h, x_q \cup x_{-q} ) ] + \log [\pi(y^h \vert x_q \cup x_{-q}, \mathcal{D}_{1:T}) ] \right \rbrace \end{eqnarray*}\]

Softmax over \(\sum_{h=1}^H \log[ u(y^h, x_q \cup x_{-q} ) ] + \log [\pi(y^h \vert x_q \cup x_{-q}, \mathcal{D}_{1:T}) ]\) for every level \(x_q\)!

SBBO - Gibbs

Assume current state of chain is \(x, y_1, \dots, y_H\). Iterate

1. For \(q=1, \dots, p\), sample \(x_q \sim g_H(x_q \vert \cdot)\)


2. For \(h=1, \dots, H\), sample \(y_h \sim g_H(y_h \vert \cdot)\), using a Metropolis-Hastings step.


3. Increase \(H\) according to chosen “cooling” schedule

SBBO - Gibbs

• Problem: recall that \(g_H(x_q \vert \cdot)\)

\[ \texttt{softmax} \left( \sum_{h=1}^H \log[ u(y^h, x_q \cup x_{-q} ) ] + \log [\pi(y^h \vert x_q \cup x_{-q}, \mathcal{D}_{1:T}) ] \right) \]

• We need analytical form of posterior predictive distribution!

• Solution idea:

  • Update \(y_1, \dots, y_H\) and \(x_q\) at the same time.
  • Use posterior predictive distribution as proposal for \(y_1, \dots, y_H\)

SBBO - Implementation details

• We run the previous algorithm increasing \(H\) until certain value.

• Last generated \(x\) is the new evaluation

• We propose several probabilistic models of response given discrete covariates for which we have sampling access to their posterior predictive distribution (PPD)

SBBO - Learners

• BLr: Bayesian second-order linear regression with horseshoe prior
• GPr: GP with Tanimoto kernel
• NGBoost (Duan et. al., 2020): natural gradient boosting with two different base learners
  • NGBdec: Decision tree
  • NGBlin: Lasso linear regression
• To compare: Simulated Annealing (SA), Random Local Search (RS)

Experimental Results

• Initial dataset \(\mathcal{D}_{1:T} = \lbrace x_t, y_t \rbrace_{t=1}^T\) with \(T=5\)

• For \(t=1:500\) iterations:

  • Use SBBO to propose next sample: \(x_{t+1}\). Utility function, expected improvement: \(u(y) = \max_y \left( y-y^*, 0 \right)\)
  • Evaluate true objective: \(y_{t+1}(x_{t+1})\)
  • Update dataset with \((x_{t+1}, y_{t+1})\)

• Report best function value after \(t\) evaluations of true objective, averaged over 10 runs (plus/minus one standard error).

Contamination Problem

• Food supply with \(d=25\) stages that maybe contaminated

• \(Z_i\) denotes fraction of food contaminated at \(i\)-th stage

• At stage \(i\), prevention effort (with cost \(c_i\)) can be made \((x_i = 1)\) decreasing contamination a random rate \(\Gamma_i\)

• If no prevention is taken \((x_i = 0)\), contamination spreads with random rate \(\Lambda_i\)

\[\begin{equation*} Z_i = \Lambda_i (1-x_i)(1 - Z_{i-1}) + (1 - \Gamma_i x_i) Z_{i-1} \end{equation*}\]

Contamination Problem - Goal

• Decide for each stage whether to intervene or not to minimize cost (\(2^d = 2^{25}\) candidate solutions)

• Ensuring fraction of cont. food does not exceed \(U_i\) with probability at least \(1-\epsilon\)

• Lagrangian relaxation

\[\begin{equation*} \arg\min_x \sum_{i=1}^d \left[ c_i x_i + \frac{\rho}{T} \sum_{k=1}^T \left(1_{\lbrace Z_{ik} > U_i \rbrace} - (1- \epsilon)\right)\right] + \lambda \Vert x \Vert_1 \end{equation*}\]

Results

RNA design

• RNA sequence: string \(A = a_1, a_2, \dots, a_p\), with \(a_i \in \lbrace A,C,G,U \rbrace\)

• Secondary structure: ensemble of paring basis with minimum free energy (MFE)

• Estimate MFE via thermodynamic model and dynamic programming has time complexity \(\mathcal{O}(p^3)\)

• Searching for sequence with MFE secondary structure. Really hard: \(4^p\) possibilites

• Use SBBO to find MFE RNA chain of lenght \(p\) with few energy evaluations

• 1D Conv. Bayesian Neural Nets!

RNA design

RNA design

Conclusions

• SBBO allows to do BO with any surrogate model (as long as we can sample from its PPD)

• Opens the door to use many models (not used before in BO)

• SBBO can be used to optimize posterior predictive utilities not only in combinatorial search spaces, also in continuous and mixed ones!

Future Work

• Can we understand why some algorithms work better than others?

• More models: Bayesian non-parametric models such as BART

• Go beyond the greedy approach…

  • Sequential decision problem
  • Generate multiple proposals at once (repulsion? Shotgun Stochastic Search?)

Thanks!

Code available at my github!

https://roinaveiro.github.io/

SBBO - Tanimoto GP

• Uncertainty on \(f(x)\) modelled through Gaussian Process

• \(x \in \lbrace 0, 1 \rbrace^p\). Kernel function:

\[\begin{equation*} k(x, x') = \frac{x \cdot x'}{\Vert x \Vert^2 + \Vert x' \Vert^2 - x \cdot x'} \end{equation*}\]

• PPD is Gaussian with certain mean and variance analytically available

SBBO - Sparse Bayesian linear regression

\[\begin{eqnarray*} && y = \alpha_0 + \sum_j \alpha_j x_j + \sum_{i,j>i} \alpha_{ij} x_i x_j + \epsilon\\ % && \alpha_k \vert \beta_k, \tau, \sigma^2 \sim \mathcal{N}(0, \beta_k^2 \tau^2 \sigma^2)\\ % && \beta_k, \tau \sim \mathcal{C}^+(0, 1)\\ % && P(\sigma^2) \propto \sigma^{-2} \end{eqnarray*}\]

• PPD accesible through MCMC (Gibbs sampler)

SBBO - NGBoost

Duan et. al. (2020):

• Output given covariates modelled through \(y \vert x \sim P_\theta (x)\)

• Where \(\theta(x)\) are obtained through an additive combination of \(M\) base learners and an initial \(\theta^{(0)}\)

\[ \theta = \theta^{(0)} - \eta \sum_{m=1}^M \rho^{(m)}\cdot f^{(m)} (x) \]

• Learners are trained to minimize a proper scoring rule using a refinement of gradient boosting

SBBO - NGBoost

• Any base learner can be used

• Base learners used: shallow decision trees and linear regressions with lasso regularization

• PPD directly accesible

Results - Why?

Results - Why?

Results - Why?
